Printed circuit board 5df 5W SMD(140 pieces)L365x10x1mm
- Light colour 2700/3000/4000 Kelvin
- Luminous flux 600 lumen
- 5 watts
- Length 365 mm, width 10 mm
Article number:
LED 5df 5W SMD(140pcs)D400x11x1,2mm
Availability:
Not available
Energy efficiency:
Product number: 199.0050-046
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 5df 5W SMD(140 pieces)L365x10x1mm
| Length: | 365 mm |
|---|---|
| Width: | 10 mm |
| Height: | 2 mm |
| Dimmable: | Yes |
| Light Temperature: | 2700/3000/4000 Kelvin (warm white to cool white) |
| Wattage: | 5 W |
| Voltage: | 24 V |
| Number of LEDS: | 140 |
| Luminous Flux: | 600 lm |
| Colour Rendering Index: | 90 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 1 |
| Weighted Energy Consumption: | 5 kw/1000h |
