Printed circuit board 24c 24W SMD(336 pieces) Band CCT
- Light colour 2700/3200/4000 Kelvin
- Luminous flux 2600 lumen
- 24 watts
- Length 1813 mm, width 7 mm
Article number:
LED 24c 24W SMD(336pcs) Band CCT
Availability:
Not available
Energy efficiency:
Product number: 199.0024-03
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 24c 24W SMD(336 pieces) Band CCT
| Length: | 1813 mm |
|---|---|
| Width: | 7 mm |
| Height: | 2 mm |
| Dimmable: | Yes |
| Light Temperature: | 2700/3200/4000 Kelvin (warm white to cool white) |
| Wattage: | 24 W |
| Number of LEDS: | 336 |
| Luminous Flux: | 2600 lm |
| Colour Rendering Index: | 90 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 54 |
| Weighted Energy Consumption: | 24 kw/1000h |
| Net Weight: | 0,20 kg |
