Printed circuit board 23b 23W SMD(672 pieces) CCT(2700/33500/4000K)
- Light colour CCT 2700/3350/4000 Kelvin
- Luminous flux 2550 lumen
- 23 watts
- Length 580 mm, width 450 mm
Article number:
LED 23b 23W SMD(672pcs) CCT(27/40K)
Availability:
Not available
Energy efficiency:
Product number: 199.0023-02
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 23b 23W SMD(672 pieces) CCT(2700/33500/4000K)
| Length: | 580 mm |
|---|---|
| Width: | 450 mm |
| Height: | 30 mm |
| Dimmable: | Yes |
| Light Temperature: | 2700/3350/4000 Kelvin (warm white to cool white) |
| Wattage: | 23 W |
| Number of LEDS: | 672 |
| Luminous Flux: | 2550 lm |
| Colour Rendering Index: | 90 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 4 |
| Weighted Energy Consumption: | 23 kw/1000h |
