Printed circuit board 15.5a 15.5W SMD(192 pieces) Band CCT
- Light colour 2700/3200/4000 Kelvin
- Luminous flux 1450 lumen
- 15.5 watts
- Length 1180 mm, width 7 mm
Article number:
LED 15,5a 15,5W SMD(192pcs) Band CCT
Availability:
Not available
Energy efficiency:
Product number: 199.0015-005
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 15.5a 15.5W SMD(192 pieces) Band CCT
| Length: | 1180 mm |
|---|---|
| Width: | 7 mm |
| Height: | 2 mm |
| Dimmable: | Yes |
| Light Temperature: | 2700/3200/4000 Kelvin (warm white to cool white) |
| Wattage: | 15,5 W |
| Number of LEDS: | 192 |
| Luminous Flux: | 1450 lm |
| Colour Rendering Index: | 90 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 53 |
| Weighted Energy Consumption: | 16 kw/1000h |
| Net Weight: | 0,20 kg |
