Driver 12sd SD-PNW012301A 300mA 12W, non-dimmable
- Not dimmable
- 300 mA, 24-42 Volt, 8-12 Watt
- Length 57 mm, width 27 mm, height 24 mm
Article number:
Driver 12sd SD-PNW012301A 300mA 12W
Availability:
Now
Product number: 290.0012-193
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.51)
Description
Driver 12sd SD-PNW012301A 300mA 12W, non-dimmable
| Length: | 57 mm |
|---|---|
| Width: | 27 mm |
| Height: | 24 mm |
| Constant Voltage/Constant Current: | 300mA |
| Dimmable: | NO |
| Material: | Plastic |
| Wattage: | 8-12 W |
| Working Voltage: | 24-42 V |
| Output Current: | 300 mA |
| IP Rating: | 20 |
| Protection Class: | II |
